Medical water system compliant with YY standards,
AAMI-compliant hemodialysis water treatment,
Exquisitely crafted high-end hemodialysis water supply solutions, ensuring safe, stable, and high-quality water support for hemodialysis treatments.
The integrated treatment process employs "pre-treatment + two-stage reverse osmosis + constant-pressure direct water supply system + full-process disinfection."
The solution has been clinically validated by thousands of domestic medical institutions, featuring a scientifically sound and rationally designed system with stable and reliable operation. The produced water quality fully complies with the YY0793-2010 standard and the international AAMI standard, meeting the water requirements of various hemodialysis centers.
The HHHD-RO water treatment equipment is specifically designed for hemodialysis rooms and centers,meeting the stringent water quality requirements essential for safe and effective hemodialysis treatment.This advanced system is fully compatible with a wide range of domestic and international dialysis machines,ensuring seamless integration into any dialysis facility.By delivering consistently high-purity water,the HHHD-RO series provides a reliable and efficient foundation for optimal dialysis therapy.For Hemodialysis department,we focus on it's water purification system for many years.
Factory: Zibo Horizon is very famous brand in China.
The products are well recognized in hospitals all over China and now our machines are exported to Italy, Russia,Africa,Turkey,UAE,Pakistan and so on with good feedback.
FAQ:
Before providing a quotation for the water treatment machine, we need to know the following information:
1- The quality of the feed water: water test report.
2- The quality of finished the purified water: such as chemical content and conductivity. We have it's standard water report for HD dept, you could share yours.
3- The production capacity of HD RO pure water (L/H) OR you can tell us how many beds need to use RO water.
Such as every 3 beds need 100LPH, every 7 beds need 300LPH, every 15 beds need 600LPH and every 20 beds need 1000LPH,we can make suggest according to beds qty.
4- A layout drawing of the installation room(s).
5- It has High-temperature heat disinfection and Chemical disinfection.
Which method does your side need? Normally, Chemical disinfection is cheaper than Heat disinfection.
>>>Generalization:
1. Comply with YY0572-2015 and YY0793-2010 hemodialysis water quality standards;
2. Meet the AAMI/ASAIO standard for hemodialysis water in the United States;
3. Meet the relevant requirements of Standard Operating Procedures for Blood Purification (2010);
4. Ion removal rate:≥ 99.5%;
5. Bacterial endotoxin removal rate: ≥ 99.9%;
6. Water quality:total bacterial count ≤ 10CFU/ml;
7. Water quality:endotoxin<0.03EU/ml.
| Model | Water Output L/H(25℃) | Power(K w) | Supply For Beds' Qty (Set) | Weight (Kg) | Dimension (L×W×H)Mm |
| HHHD-RO | 300 | 380V/4.0 | 3-7 | 260 | 900x750x1600 |
| 600 | 380V/5.0 | 5-15 | 300 | 1500x750x1750 | |
| 1000 | 380V/7.0 | 10-25 | 400 | 1500x750x1750 | |
| HHHD-RO | 1200 | 380V/10.0 | 15-30 | 480 | 1200x750x1750 |
| 1500 | 380V/10.0 | 20-40 | 550 | 1200x750x1750 | |
| HHHD-RO | 2000 | 380V/12.0 | 30-70 | 650 | 1500x750x1750 |
| 3000 | 380V/12.0 | 40-80 | 750 | 1500x800x1750 |
>>>The HHHD-RO Water Treatment System Consists of:
1. Automatic Pretreatment System:
Comprising a raw water booster pump,pre-filter,multimedia filter,activated carbon filter,water softener,and a final precision filter to ensure feed water quality for the downstream RO process.
2. Reverse Osmosis Host:
Featuring a two-stage RO design for high-purity water production,a concentrate water recycling system to enhance water efficiency,and an integrated automatic control system for reliable operation.
3. Water Supply & Distribution Loop:
Engineered with a U-type main circulation loop and a U-type secondary circulation loop to maintain constant flow velocity and prevent bacterial growth,ensuring water purity at the point of use.
4. Automatic Disinfection System (Optional):
4.1 Chemical Disinfection System
4.2 Pasteurization (90°C) and Over-temperature (121°C) Sterilization System
5.Remote Monitoring System:
Enables real-time remote supervision of various operating parameters and equipment working status via mobile phone or computer,facilitating proactive system management and maintenance.
