What It Is
A pure steam generator produces pure steam from Water for Injection (WFI) or purified water.
Applications
Widely used in healthcare, biopharmaceuticals, and food industry for sterilization of equipment and instruments.
Key Benefit
Effectively prevents re-contamination by heavy metals, pyrogens, and other impurities.
Steam Quality Requirement
Pure steam must be dry saturated steam at 121 °C.
High-performance multi-effect distillation system with double-tube-sheet design, SUS316L wetted parts, PTFE seals, and three-stage separation (falling film, gravity, mist elimination). Features automatic orbital welding, electrochemical polishing, passivation, and asbestos-free insulation for reliable pure steam/water production with zero cross-contamination risk.
Pure steam generator producing dry saturated steam at 121 °C from WFI or purified water. Designed for pharmaceutical, hospital, and food sterilization applications, eliminating heavy metals and pyrogens to prevent re‑contamination while avoiding superheat‑related sterilization failures. Reliable, compliant, and process‑safe.
Structural Design
Double tube sheets for both evaporator and preheater
Internal expansion + external welding to prevent cross-contamination
Materials
All contact parts (raw water, pure steam, sampling condenser): SUS316L stainless steel
Seals: PTFE
Frame and supports: stainless steel
Three-Stage Separation
Falling film evaporation + gravity separation + mist elimination
Pickling & Passivation
Standard pickling and passivation on all working surfaces
Surface Finish
Electrochemical polishing for high surface smoothness
Welding Quality
Automatic argon-shielded orbital welding for consistent quality
Thermal Insulation
Asbestos-free aluminum silicate needled felt, covered with stainless steel cladding
